Palet Dolly

Product Overview

Palet Dolly

Miles Pallet Dolly can be safely used for transporting containers and pallets with its high internal and external strength. While providing maximum security to the user, it offers time-saving and high performance in the execution of pallet operations.

All parts used in the design and production of the Miles Pallet Dolly have been selected in accordance with occupational health and safety principles. Miles Pallet Dollies are manufactured according to AHM, VDE, and IATA standards.

Quick Contact

Product Request

Thank you
Error occurred while sending email. Please try again later.
Technical Sheet

Core Specifications

MODEL Pallet Dolly 10FT
  Pallet Dolly 20FT
  Pallet Dolly 40FT
  (Miles 6035)
TECHNICAL SPECIFICATIONS
Platform dimension: 2575x3390 mm
Container types it can carry: LD1, LD2, LD3, LD4, LD8
Palet types it can carry: (P6P/LD39), (P1P/LD9)
Total length: 3980 mm
Ground clearance: 510 mm
Max. carrying capacity: 6800 kg
Chassis: Hot dip galvanized steel
Wheels: 400x100x8
Weight: 1050 kg
Max. speed: 25 km/h
Drawbar angle: 90°
Weight: 650 kg
Max. speed: 25 km/h
Drawbar angle: 90°
